Low viscosity UV adhesive for coating and encapsulation

loxeal-30-83
loxeal-30-83
Applications
  1. Loxeal 30-83 is developed for use as a doming and coating adhesive.Suitable for encapsulating electronic components, designed for low power curing systems.It is used for applications requiring high thermal shocks(upto 270°C) such as in the soldering process.
Replaces Solvent Bonding, Ultrasonic Welding
Available pack size 50ml, 250ml, 2litre
Standards DIN, REACH, RoHS
Related Accessories
(Click image to explore more)

Download
TDS

Application
Tips

Specifications

Chemical Composition Acrylic resins
Curing Mechanism Polymerization on exposure to UV rays
Recommended substrates Glass/Glass ,Glass/Metal , Transparent Plastics (PC,ABS,PMMA) .
Recommended UV Waves 365 to 420 nm
Recommended Intensity 100mW/cm²
Curing time Depends on Substrates .
Tensile Strength 8 -15 N/mm²
Service Temperature -55°C to 120°C

Features and Benefits

It is a medium viscous product that tacks in few seconds.
Has very good elongation of 50-100%.
Provides sustained temperature resistance of 120°C.

Notes

  • Loxeal 30-83provides a protective colourless film after exposure at high temperature with no shrinkage behavior.
  • Some users compromise on the wavelength of UV bulb and intensity.It must be noted that for best performance wavelength must be 365-420 nm and intensity of 100mW/cm².
  • Curing time depends on depth of adhesive bondline and must be factored in while calculating production time.
